Cat6 UTP 23 AWG Solid, Blue, 305 Meter(s)
Conductor Size: 23AWG
Conductor Material: Solid Bare Copper
Insulation Material: HDPE
Insulation Diameter: 1.00 ± 0.05mm
Insulation Thickness: 0.18mm Min.
Jacket Material: PVC
Jacket Diameter: 5.80 ± 0.20mm
Jacket Colour: Blue
Marking: Each meter printed with specs and meter marking
Conductor Resistance: 93.8 Ω/km Max.
Insulation Resistance: 5000 Mega Ω/km Min.
Dielectric Strength: 2.35 Max.
Operating Frequency: 0 to 250 MHz
NVP: 69%
DATA SHEET
Cat6 UTP 23 AWG Solid, Grey, 305 Meter(s)
Conductor Size: 23AWG
Conductor Material: Solid Bare Copper
Insulation Material: HDPE
Insulation Diameter: 1.00 ± 0.05mm
Insulation Thickness: 0.18mm Min.
Jacket Material: PVC
Jacket Diameter: 5.80 ± 0.20mm
Jacket Colour: Grey
Marking: Each meter printed with specs and meter marking
Conductor Resistance: 93.8 Ω/km Max.
Insulation Resistance: 5000 Mega Ω/km Min.
Dielectric Strength: 2.35 Max.
Operating Frequency: 0 to 250 MHz
NVP: 69%
DATA SHEET
INTERFACE (R) CABLES 2C 0.35 SQ.MM (22AWG) FS 300V 80°C FR VW-1 PVC CABLE UL AWM 2464 E486063 ROHS
Packing: Reel
Number of cores: 2
Wire Gauge: 22
Conductor Strand: 7 x 0.25 mm
Conductor Material: Bare Copper (OFC)
Insulation Material: Polyethylene (PE)
Insulation Diameter: 1.3 mm
Insulation Thickness: 0.27 mm
Voltage: 300V
Operating Temperature: -20°C to +80°C
Colour: Grey (RAL7001)
UL Rating: 2464
View/ Download Data Sheet
INTERFACE® CABLES 2C 0.56 SQ.MM (20AWG) FS 300V 80°C FR VW-1 PVC CABLE UL AWM 2464 E486063 ROHS
Packing: Reel
Number of cores: 2
Wire Gauge: 20
Conductor Strand: 7 x 0.32 mm
Conductor Material: Bare Copper (OFC)
Insulation Material: Polyethylene (PE)
Insulation Diameter: 1.5 mm
Insulation Thickness: 0.27 mm
Voltage: 300V
Operating Temperature: -20°C to +80°C
Colour: Grey (RAL7001)
UL Rating: 2464
View/ Download Data Sheet
INTERFACE® CABLES 2C 0.90 SQ.MM (18AWG) FS 300V 80°C FR VW-1 PVC CABLE UL AWM 2464 E486063 ROHS
Packing: Reel
Number of cores: 2
Wire Gauge: 18
Conductor Strand: 7 x 0.40 mm
Conductor Material: Bare Copper (OFC)
Insulation Material: Polyethylene (PE)
Insulation Diameter: 1.7 mm
Insulation Thickness: 0.25 mm
Voltage: 300V
Operating Temperature: -20°C to +80°C
Colour: Grey (RAL7001)
UL Rating: 2464
View/ Download Data Sheet
INTERFACE® CABLES 4C 0.35 SQ.MM (22AWG) FS 300V 80°C FR VW-1 PVC CABLE UL AWM 2464 E486063 ROHS
Packing: Reel
Number of cores: 4
Wire Gauge: 22
Conductor Strand: 7 x 0.25 mm
Conductor Material: Bare Copper (OFC)
Insulation Material: Polyethylene (PE)
Insulation Diameter: 1.3 mm
Insulation Thickness: 0.27 mm
Voltage: 300V
Operating Temperature: -20°C to +80°C
Colour: Grey (RAL7001)
UL Rating: 2464
View/ Download Data Sheet
INTERFACE® CABLES 4C 0.56 SQ.MM (20AWG) FS 300V 80°C FR VW-1 PVC CABLE UL AWM 2464 E486063 ROHS
Packing: Reel
Number of cores: 4
Wire Gauge: 20
Conductor Strand: 7 x 0.32 mm
Conductor Material: Bare Copper (OFC)
Insulation Material: Polyethylene (PE)
Insulation Diameter: 1.5 mm
Insulation Thickness: 0.27 mm
Voltage: 300V
Operating Temperature: -20°C to +80°C
Colour: Grey (RAL7001)
UL Rating: 2464
View/ Download Data Sheet
INTERFACE® CABLES 4C 0.90 SQ.MM (18AWG) FS 300V 80°C FR VW-1 PVC CABLE UL AWM 2464 E486063 ROHS
Packing: Reel
Number of cores: 4
Wire Gauge: 18
Conductor Strand: 7 x 0.40 mm
Conductor Material: Bare Copper (OFC)
Insulation Material: Polyethylene (PE)
Insulation Diameter: 1.7 mm
Insulation Thickness: 0.25 mm
Voltage: 300V
Operating Temperature: -20°C to +80°C
Colour: Grey (RAL7001)
UL Rating: 2464
View/ Download Data Sheet
INTERFACE® CABLES 8C 0.35 SQ.MM (22AWG) FS 300V 80°C FR VW-1 PVC CABLE UL AWM 2464 E486063 ROHS
Packing: Reel
Number of cores: 4
Wire Gauge: 22
Conductor Strand: 7 x 0.25 mm
Conductor Material: Bare Copper (OFC)
Insulation Material: Polyethylene (PE)
Insulation Diameter: 1.3 mm
Insulation Thickness: 0.27 mm
Voltage: 300V
Operating Temperature: -20°C to +80°C
Colour: Grey (RAL7001)
UL Rating: 2464
View/ Download Data Sheet
INTERFACE® FLAT CABLE 10 CORE 28 AWG 1MM PITCH PVC GREY COLOUR 100 FT/R
Number of cores:10
Conductor Spacing:1mm ± 0.2mm
Wire Gauge:28
Conductor Strand:7/0.127mm
Conductor Material:Tinned Copper
Insulation Material:Polyvinyl Chloride (PVC)
Insulation Diameter:0.90±0.10mm
Voltage:300V
Operating Temperature:105°C
Colour:Grey
UL Rating:2651
Packing:100 Ft Reel
View/ Download Data Sheet
INTERFACE® FLAT CABLE 14 CORE 28 AWG 1.27MM PITCH PVC GREY COLOUR 100 FT/R
Packing:Reel
Number of cores:14
Wire Gauge:28
Conductor Strand:7/0.127mm
Conductor Material:Tinned Copper
Insulation Material:Polyvinyl Chloride (PVC)
Insulation Diameter:
Insulation Thickness:09
Voltage:300V
Operating Temperature:105°C
Colour:Grey
UL Rating:2651
View/ Download Data Sheet
INTERFACE® FLAT CABLE 14 CORE 28 AWG 1MM PITCH PVC GREY COLOUR 100 FT/R
Number of cores:14
Conductor Spacing:1mm ± 0.2mm
Wire Gauge:28
Conductor Strand:7/0.127mm
Conductor Material:Tinned Copper
Insulation Material:Polyvinyl Chloride (PVC)
Insulation Diameter:0.90±0.10mm
Voltage:300V
Operating Temperature:105°C
Colour:Grey
UL Rating:2651
Packing:100 Ft Reel
View/ Download Data Sheet
