15 PIN MALE D-SUB HIGH DENSITY SOLDER CONNECTOR
Pitch : 2.54mm Connector Type: Plug, Male Pins Number of Positions: 15 Number of Rows: 3 Termination: Solder Cup Shell Material: Steel, Nickel Plated Contact Material: Copper Alloy Contact Finish: Gold Flash Wire Gauge: 24-28 AWG DATA SHEET
2.5mm pitch single row 2 pin plug header straight, white
Pitch: 2.54mm
Contact Type: Plug
Number of Positions: 2
Number of Rows: 1
Termination: Solder
Operating Temperature: -25?C to 85?C
Color: White
Material: PA66 (UL 94V - 0)
Mates With: N-1250H02
Packing: Polybag
26 PIN MALE D-SUB HIGH DENSITY SOLDER CONNECTOR
Pitch : 2.54mm Connector Type: Plug, Male Pins Number of Positions: 26 Number of Rows: 3 Termination: Solder Cup Shell Material: Steel, Nickel Plated Contact Material: Copper Alloy Contact Finish: Gold Flash Wire Gauge: 24-28 AWG DATA SHEET
3120A – DeviceBus® for InterBus®-S, 3 Pr #24 Str TC, PO Ins, OS+TC Brd, PUR Jkt, AWM
DeviceBus® for InterBus®-S, 3 Pair 24AWG (7x32) Tinned Copper, PO Insulation, Overall Beldfoil®+Tinned Copper Braid(90%) Shield, PUR Outer Jacket, AWM 20233
DATA SHEET
4.2mm pitch single row 2 pin plug header minifit straight, white
Pitch: 4.2mm
Contact Type: Plug
Number of Positions: 2
Number of Rows: 1
Termination: Solder
Operating Temperature: -25?C to 85?C
Color: White
Material: PA66 (UL 94V - 0)
Packing: Polybag
44 PIN MALE D-SUB HIGH DENSITY SOLDER CONNECTOR
Pitch : 2.54mm
Connector Type: Plug, Male Pins
Number of Positions: 44
Number of Rows: 3
Termination: Solder Cup
Shell Material: Steel, Nickel Plated
Contact Material: Copper Alloy
Contact Finish: Gold Flash
Wire Gauge: 24-28 AWG
DATA SHEET
62 PIN MALE D-SUB HIGH DENSITY SOLDER CONNECTOR
Pitch : 2.54mm
Connector Type: Plug, Male Pins
Number of Positions: 62
Number of Rows: 3
Termination: Solder Cup
Shell Material: Steel, Nickel Plated
Contact Material: Copper Alloy
Contact Finish: Gold Flash
Wire Gauge: 24-28 AWG
DATA SHEET
70518BLF
Features :-
Component Type : Plastic dust cap
Shell Size: E
Material Housing : Plastic
Number of Contacts: 9 Position
EMI/RFI Performance: Non Shielded
Packaging: Bulk Packaging
70523BLF
Features :-
Component Type : Plastic dust cap
Shell Size: E
Material Housing : Plastic
Number of Contacts: 9 Position
EMI/RFI Performance: Non Shielded
Packaging: Bulk Packaging
75 Ohm Analog Video Coax, RG-59, 22 AWG Str BC, 95% BC Braid, FEP Jkt, CMP
75 Ohm Analog Video Coax, RG-59, 22 AWG (7x30) Bare Copper Conductor, FEP Insulation, 95% Bare Copper Braid Shield, FEP Jacket, CMP.
DATA SHEET
